Figure 4.
Installing the Right Cover
1. Place the right cover on the computer.
2. Install the screws that secure the right cover to the computer.
3. Follow the procedures in After Working Inside Your Computer.
Removing the 5.25-inch Optical Drive
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. right cover
3. Disconnect the data and power cables from the back of the optical drive.
4. Press the release latch and slide the optical drive outward to release it from the drive bay [1, 2].
41
