Removing and installing components
This section provides detailed information on how to remove or install the components from your computer.
Recommended Tools
The procedures in this document may require the following tools:
• Small slotted-tip screwdriver
• #2 Phillips screwdriver
• #1 Phillips screwdriver
• Small plastic scribe
For how-to videos, documentation, and troubleshooting solutions, scan this QR code, or click here:
System Overview
Figure 1. Front and Back View of T7910 Computer
1 power button/power light
2 USB 3.0 connector
3 optical drive (optional)
4 optical-drive eject button (optional)
5 USB 2.0 connectors
2
Removing and installing components 7
