5 Press rmly on the heatsink and rotate clockwise.
6 Install:
a memory shroud (center)
b left cover
7 Follow the procedures in After Working Inside Your Computer.
Removing the Liquid Cooler Heatsink (Optional)
1 Follow the procedures in Before Working Inside Your Computer.
2 Remove:
a left cover
b memory shroud (center)
3 Press rmly on the heatsink and rotate anti-clockwise.
Removing and installing components
25
