Figure 3. Inside View of T7910 Computer
1. system fans
2. speaker
3. PCI retention latch
4. power-supply unit
5. PCI retention latch
Removing the Power Supply Unit (PSU)
1. Follow the procedures in Before Working Inside Your Computer.
2. If the PSU is locked, remove the screw to unlock the PSU. For more information, see the PSU Lock
Feature.
3. Press and hold the blue tab, then pull the power supply unit away from the computer.
12
