8 Lift the hard drive in an upward direction to remove it from the hard-drive bracket.
9 If a 2.5 inch hard drive is installed , Push the retention clips in an outward direction and lift up the drive to remove it from the 3.5 inch
hard-drive caddy.
Installing the Hard Drive
1 If a 2.5–inch or 3.5–inch hard drive is installed, place the hard drive to the hard-drive caddy until it snaps to its place.
2 Flex the hard-drive bracket and then insert the hard drive into the bracket.
3 Slide the hard-drive bracket into its compartment and close the hard-drive bracket clasp.
4 Install the front cover.
5 Follow the procedures in After Working Inside Your Computer.
Removing the Left Cover
1 Follow the procedures in Before Working Inside Your Computer.
2 Pull up the cover release latch on the side of the computer.
14
Removing and installing components
