Dell D02X

Table 24. External Connectors
Feature Specication
Audio
• front panel — mic-in, headphone-out
• back panel — line-out, mic in/line In
Network
Tower 7910 two RJ-45 connector
Serial one 9-pin connector
USB
Tower 7910
• front panel — three USB 2.0, and one USB 3.0
• back panel — three USB 2.0, and one USB 3.0
• internal — three USB 2.0
Video Video card dependent
• DVI connector
• mini DisplayPort
• DisplayPort
• DMS-59
Table 25. Internal Connectors
Feature Specication
System power one 28–pin connector
System fans three 4-pin connectors
Thunderbolt sideband connector one 5-pin connector
Processor fans
Tower 7910 two 5-pin connectors
HDD fans
Tower 7910 three 5-pin connectors
Memory
Tower 7910 sixteen 288–pin connectors
Processor
Tower 7910 two LGA-2011 sockets
Back I/O:
PCI Express
PCI Express x4
Tower 7910 one 98–pin connector, one 164-pin connector
PCI Express x16
Tower 7910 two 164-pin connectors (four when optional second processor is installed)
PCI 2.3 one 124-pin connector
Front I/O:
Front USB one 14–pin connector
Technical Specications 69
