About this task
The following image indicates the location of the cable cover and provides a visual representation of the removal procedure.
NOTE: The cable cover is an optional accessory.
Steps
Pull the cable cover from the top to lift the cable cover from the chassis.
Installing the cable cover
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the cable cover and provides a visual representation of the installation procedure.
NOTE: The cable cover is an optional accessory.
16 Removing and installing components
