2. Install the top cover.
3. Install the left-side cover.
4. Follow the procedure in After working inside your computer.
Side light
Removing the side light
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
3. Remove the top cover.
4. Remove the right-side cover.
5. Remove the front bezel.
About this task
NOTE: Side light is available only on computers that are shipped with clear left-side covers.
The following images indicate the location of the side light and provide a visual representation of the removal procedure.
Steps
1. Lay the computer on its right side.
2. Disconnect the side-light cable from the system board.
26
Removing and installing components
