Installing the top cover
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the top cover and provides a visual representation of the installation procedure.
Steps
Align the tabs on the top cover with the slots on the chassis and snap the top cover into place.
Next steps
1. Install the left-side cover.
2. Follow the procedure in After working inside your computer.
Right-side cover
Removing the right-side cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
3. Remove the top cover.
About this task
The following images indicate the location of the right-side cover and provide a visual representation of the removal procedure.
Removing and installing components
21
