Maintaining Your Printer | 345
Always keep the side that was attached to the printer facing up.
WARNING:
• Never let the side that was attached to the printer face down. This may cause the toner to
spill out.
5 Pull out the cleaning rod from inside the printer.
6 Insert the cleaning rod into one of the four holes of the tabs on the drum cartridges
until it stops, and then pull it out.
NOTE:
• Insert the cleaning rod with the pad side up.
• It is not necessary to move the cleaning rod back and forth repeatedly.
