Dell Latitude 5290 2-in-1 User Manual

c Release the speakers from the tablet [3].
NOTE: The speaker is attached with an adhesive, ensure to pull gently for reuse of the tape in installing the speaker.
Installing speaker
1 Insert the speaker in the block on the system board.
2 Connect the cables to the system board.
3 Press the speaker to glue it to the adhesive paste on the system.
4 Install the:
a Display panel
b uSIM/microSD
NOTE: uSIM card is installed only on tablets shipping with WWAN module.
5 Follow the procedure in After working inside your tablet.
Battery
Removing the battery
1 Follow the procedure in Before working inside your tablet.
2 Remove the:
a uSIM/micro SD card
NOTE
: uSIM card slot is available only on tablets shipping with WWAN module.
b display panel
3 To remove the battery:
a Release the adhesive tape that secures the battery connector to the system board.
b Disconnect the battery cable from the connector on the system board.
NOTE
: Ensure to pull the cable by the lever of the battery connector, to avoid damage to the pin.
c Remove the M2.0 x 4.0 screws (4) that secure the battery to the tablet [1].
d Lift the battery from the tablet [2].
18
Removing and installing components

Dell Latitude 5290 2-in-1 Specifications

General

Operating System	Windows 10 Pro
Graphics	Intel UHD Graphics 620
Processor	i7-8650U
RAM	8GB
Storage	256GB SSD
Battery	42 WHr
Camera	Front: 8 MP camera Rear: 5 MP camera
Ports	2 x USB-C
Wireless	Intel Dual Band Wireless-AC 8265, Bluetooth 4.2
