Dell Latitude 5290 2-in-1 User Manual

NOTE: If you can easily disconnect the RTC battery cable from beneath the connector on the system board, you need not
remove the system board to remove the RTC battery.
Installing the RTC battery
1 Insert the RTC battery to the slot on and ax it to the back cover.
2 Connect the RTC battery cable to the connector beneath the system board.
3 Install the:
a battery
b display panel
c uSIM/microSD card
NOTE
: uSIM card is installed only on tablets shipping with WWAN module.
4 Follow the procedure in After working inside your tablet.
USH board
Removing the USH board
1 Follow the procedure in Before working inside your tablet.
2 Remove the:
a uSIM/microSD card
NOTE
: uSIM card slot is available only on tablets shipping with WWAN module.
b display panel
32
Removing and installing components

Dell Latitude 5290 2-in-1 Specifications

General

Operating System	Windows 10 Pro
Graphics	Intel UHD Graphics 620
Processor	i7-8650U
RAM	8GB
Storage	256GB SSD
Battery	42 WHr
Camera	Front: 8 MP camera Rear: 5 MP camera
Ports	2 x USB-C
Wireless	Intel Dual Band Wireless-AC 8265, Bluetooth 4.2
