Installing system board
1 Align the system board with the screw holders on the tablet.
2 Tighten the M2.0 x 2.5 screws to secure the system board to the tablet.
NOTE: Remember to align the Type-C port and tighten the two screws to secure the port to the system chassis.
3
Route the antenna cables through the routing clips and channels.
4 Connect the docking board cable, speaker cable and the USH board cable to the connectors on the system board.
5 Install the:
a heat sink
b rear facing camera
c front facing camera
d system fan
e WLAN card
f SSD card
g battery
h display panel
i uSIM/microSD
NOTE: uSIM card is installed only on tablets shipping with WWAN module.
6 Follow the procedure in After working inside your tablet.
Real time clock (RTC)
Removing the RTC battery
RTC battery connector is located beneath the system board.
1 Follow the procedure in Before working inside your tablet.
2 Remove the:
a uSIM and/or microSD card
NOTE
: uSIM card slot is available only on tablets shipping with WWAN module.
b display panel
c battery
d system board
3 To remove the RTC battery:
a Disconnect the RTC battery cable from the connector beneath the system board.
b Lift the RTC battery from the tablet.
Removing and installing components
31
