Installing the smart card cage
1 Insert the smart cage into the slot on the tablet.
2 Replace the M2.0 x 2.5 screws screws to secure the smart card cage to the tablet.
3 Connect the smart cable to the smart card module.
4 Install the:
a display panel
b uSIM/microSD card
NOTE: uSIM card is installed only on tablets shipping with WWAN module.
5 Follow the procedure in After working inside your tablet.
Docking board
Removing the docking board
1 Follow the procedure in Before working inside your tablet.
2 Remove the:
a uSIM/microSD card
NOTE
: uSIM card slot is available only on tablets shipping with WWAN module.
b display panel
c battery
3 To release the docking board:
a Lift the latch and dDisconnect the docking board cable from the system board [1].
b Peel the docking board cable from adhesive on the tablet [2].
c Remove the M2.0 x 2.0 screws (2) securing the docking board bracket to the docking board [3].
d Lift the docking board from the tablet [4].
26
Removing and installing components
