Dell Latitude 5290 2-in-1 User Manual

NOTE: Micro-SIM card slot is available only on tablets shipping with WWAN module.
b Display panel
3 To remove the front camera:
a Remove the conductive tape covering the shielding cover [1].
NOTE: Ensure to pull the conductive tape gently to reuse in installing the front camera.
b Lift the shielding cover covering the front cameracable connected to the system board[2].
c Use a plastic scribe to disconnect the front camera cable [3]
NOTE: Ensure to peel o the adhesive tape that secures the front camera to the rear camera. The front camera cable
is glued to the rear camera, ensure to gently peel o, to remove the screw that secures the rear camera to the system
board.
d Remove the M1.6 x 3.0 screws (2) securing the front camera module [4].
e Lift the front camera module from the tablet [5].
Installing the front camera
1 Insert the camera module into the slot on the tablet.
2 Replace the M1.6 x 3.0 screws to secure the front camera module.
3 Connect the front camera cable to the system board.
4 Place the covering shield to cover the front camera module.
NOTE
: Handle the covering shield with care else it may break.
5 Ax the tape to secure the shield cover.
6 Install the:
a display panel
b uSIM/microSD card
Removing and installing components
23

Dell Latitude 5290 2-in-1 Specifications

General

Operating System	Windows 10 Pro
Graphics	Intel UHD Graphics 620
Processor	i7-8650U
RAM	8GB
Storage	256GB SSD
Battery	42 WHr
Camera	Front: 8 MP camera Rear: 5 MP camera
Ports	2 x USB-C
Wireless	Intel Dual Band Wireless-AC 8265, Bluetooth 4.2
