Wireless Wide Area Network (WWAN) Card
Dell™ Latitude™ E4300 Service Manual
Removing a WWAN Card
Replacing a WWAN Card
CAUTION: Before working inside the computer, read the safety information that shipped with the
computer. For additional safety best practices information, see the Regulatory Compliance Homepage on
www.dell.com at: www.dell.com/regulatory_compliance.
Your computer supports a Wireless Wide Area Network (WWAN) card. If you ordered a WWAN card with your computer, the
card is already installed.
Removing a WWAN Card
1. Follow the instructions in What You Need to Know For Your Safety.
2. Close the display and turn the computer upside-down.
3. Loosen the captive screw on the WLAN/WWAN cover.
4. Remove the WLAN/WWAN cover.
5. Disconnect the antenna cables from the WWAN card.
