Coin-Cell Battery
Dell™ Latitude™ E4300 Service Manual
Removing the Coin-Cell Battery
Replacing the Coin-Cell Battery
CAUTION: Before working inside the computer, read the safety information that shipped with the
computer. For additional safety best practices information, see the Regulatory Compliance Homepage on
www.dell.com at: www.dell.com/regulatory_compliance.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching a connector on the back panel of the computer.
NOTICE: To prevent damage to the system board, remove the main battery before you service the
computer.
Removing the Coin-Cell Battery
1. Follow the instructions in What You Need to Know For Your Safety.
2. Remove the LED dashboard cover (see Removing the LED Dashboard Cover
).
3. Remove the keyboard (see Removing the Keyboard
).
4. Disconnect the battery cable from the system board.
5. Lift the battery out of the battery compartment.
1 battery cable and connector 2 coin-cell battery
