Replacing the Speaker Assembly
NOTE: This procedure assumes that you have completed the removal procedure first.
NOTE: The left and right speakers are marker "L" and "R," respectively.
1. Align the speakers over their respective screw holes in the computer base.
2. Reconnect the speaker cable to the system board.
3. Replace the two M2.5 x 4-mm screws on the right speaker and the two M2.5 x 2.3-mm screws on the left speaker.
4. Replace the palm rest (see Replacing the Palm Rest
).
5. Replace the display assembly (see Replacing the Display Assembly
).
6. Replace the keyboard (see Replacing the Keyboard
).
7. Follow the instructions in After Working on Your Computer
.
