System Fan: Dell Latitude E4300 Service Manual
file:///C|/Biz%20Client/2015/Lola%20(Defect%20Fix)/fan.htm[5/25/2015 11:14:13 AM]
1. Reseat the fan in the computer base, aligning the screws hole in the fan with the screw hole in the computer base.
2. Install the M2.5 x 5-mm screw to secure the fan.
3. Reconnect the fan connector to the system board connector.
4. Replace the palm rest (see Replacing the Palm Rest
).
5. Replace the display assembly (see Replacing the Display Assembly
).
6. Replace the keyboard (see Replacing the Keyboard
).
7. Replace the LED dashboard cover (see Replacing the LED Dashboard Cover
).
8. Follow the instructions in After Working on Your Computer
.
