Dell Latitude E6230 - Speaker Procedures

Removing the Speakers
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the:
a) SD Card
b) ExpressCard
c) battery
d) base cover
3. Disconnect the speaker cable.
4. Remove the speaker cable from the routing channel.
