Battery
• 6-cell (58 WHr) Lithium-ion battery
Dimensions:
3-cell
Depth 29.97 mm (1.18 inches)
Height 19.80 mm (0.78 inch)
Width 208.00 mm (8.19 inches)
6-cell
Depth 54.10 mm (2.13 inches)
Height 20.85 mm (0.82 inch)
Width 214.00 mm (8.43 inches)
Weight:
3-cell 172.37 g (0.38 lb)
6-cell 335.66 g (0.74 lb)
Voltage 11.10 VDC
Temperature range:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Non-Operating –40 °C to 65 °C (–40 °F to 149 °F)
Coin-cell battery 3 V CR2032 lithium coin cell
AC Adapter
Type 65 W and 90 W
Input voltage 100 VAC to 240 VAC
Input current (maximum) 1.50 A/1.60 A/1.70 A
Input frequency 50 Hz to 60 Hz
Output power 65 W and 90 W
Output current 3.34 A and 4.62 A (continuous)
Rated output voltage 19.5 +/– 1.0 VDC
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F)
Non-Operating –40 °C to 70 °C (–40 °F to 158 °F)
78
