Dell Latitude E6420 - Palm Rest Assembly Service; Removing the Palm Rest Assembly

Palm Rest 21
Removing the Palm Rest Assembly
1. Follow the procedures in Before Working On Your Computer .
2. Remove the
ATG Handle (only for E6420 ATG systems).
3. Remove the
ATG Port Cover (only for E6420 ATG systems).
4. Remove the Battery .
5. Remove the
SD Card .
6. Remove the Base Cover .
7. Remove the
Optical Drive .
8. Remove the Hard Drive .
9. Remove the WWAN Card .
10. Remove the
Bluetooth Card .
11. Remove the Keyboard Trim .
12. Remove the
Keyboard .
13. Remove the screws that secure the palm rest assembly to the computer.
14. Turn the system and remove the screws that secure the palm rest assembly
to the computer.
65
