Installing the Solid State Drive (SSD)
1. Insert the SSD into the connector on the system board.
2. Tighten the screw to secure the SSD to the computer.
3. Install the:
a. battery
b. base cover
4. Follow the procedure in After working inside your computer.
PCIe Solid State Drive (SSD)
Removing the optional PCIe SSD
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
3. To remove the PCIe SSD:
a. Remove the screws that secure the SSD bracket to the computer [1].
b. Remove the SSD bracket [2].
c. Remove the SSD from the computer [3].
