Installing the coin cell battery
1. Affix the coin cell battery to the system board.
2. Connect the coin cell battery cable to the connector on the system board.
3. Install the:
a. battery
b. base cover
4. Follow the procedure in After working inside your computer.
WLAN card
Removing the WLAN card
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
3. To remove the WLAN card:
a. Remove the screw that secures the metal bracket to the WLAN card [1].
b. Remove the metal bracket [2].
c. Disconnect the WLAN cables from the connectors on the WLAN card [3].
d. Remove the WLAN card from the computer [4].
16
