Installing the camera
1. Place the camera on the display assembly.
2. Connect the camera cable to the connector on the display assembly
3. Affix the adhesive to secure the camera to the display assembly.
4. Install the:
a. display panel
b. display bezel
NOTE: This is applicable only for non touch systems.
c. display assembly
d. battery
e. base cover
5. Follow the procedure in After working inside your system.
Palmrest
Replacing the palmrest
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
c. memory module
d. SSD
e. dock frame
f. WLAN card
g. WWAN card
h. heat sink assembly
i. power connector port
j. coin cell battery
k. display assembly
l. speakers
m. smart card cage
n. keyboard
o. system board
NOTE: The component you are left with is the palmrest.
38
