Dell Latitude E7270 - Installing the Optional Pcie SSD; Smart Card Module; Removing the Smart Card Cage

Installing the optional PCIe SSD
1. Insert the SSD into the connector on the system board.
2. Place the SSD bracket over the SSD and tighten the screws to secure it to the computer.
3. Install the:
a. battery
b. base cover
4. Follow the procedure in After working inside your computer.
Smart card module
Removing the smart card cage
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
c. SSD
3. To remove the smart card cage:
a. Disconnect the smart card cable [1, 2].
b. Remove the screws that secure the smart card cage to the computer [3].
c. Slide and lift the smart card cage from the computer [4].
13
