Table 2. Battery charge LED indicator
Amber blinking pattern Problem description Suggested resolution
2,1 CPU CPU failure
2,2 System board: BIOS ROM System board, covers BIOS corruption or ROM error
2,3 Memory No memory/RAM detected
2,4 Memory Memory/RAM failure
2,5 Memory Invalid memory installed
2,6 System board: Chipset System board/Chipset error
2,7 LCD Replace the system board
3,1 RTC Power Failure CMOS battery failure
3,2 PCI/Video PCI or video card/chip failure
3,3 BIOS Recovery 1 Recovery image not found
3,4 BIOS Recovery 2 Recovery image found but invalid
The blinking patterns will consist of 2 set of numbers being represented by (First Group: Amber blinks, Second Group: White blinks)
NOTE:
1. First Group: The LED blinks 1 to 9 times followed by a brief pause with LED off at the interval of 1.5 seconds.(This is in
Amber color)
2. Second Group: The LED blinks 1 to 9 times, that would be then followed by a longer pause before the next cycle starts
again at the interval of 1.5 seconds.(This is in White color)
For Example: No Memory detected (2,3), Battery LED blinks two times of amber color followed by a pause, and then blinks three
times of white color. The Battery LED will pause for 3 seconds before the next cycle repeat itself again.
Battery status lights
If the computer is connected to an electrical outlet, the battery light operates as follows:
Alternately blinking
amber light and
white light
An unauthenticated or unsupported non-Dell AC adapter is attached to your laptop.
Alternately blinking
amber light with
steady white light
Temporary battery failure with AC adapter present.
Constantly blinking
amber light
Fatal battery failure with AC adapter present.
Light off Battery in full charge mode with AC adapter present.
White light on Battery in charge mode with AC adapter present.
55
