Installing the display panel
1. To install the display panel for non touch systems:
a. Connect the eDP cable to the connector on the back of the display panel and fix the adhesive tape.
b. Align the display panel with the tabs on the display assembly.
c. Tighten the screws to secure the display panel to the display assembly.
2. To install the display panel for touch systems:
a. Place the display panel facedown.
b. Place the display assembly over the display panel and slide it forward.
c. Connect the eDP cable to the connector on the back of the display panel and fix the adhesive tape.
d. Turn the display assembly over.
e. Align the display panel with the tabs on the display assembly.
f. Press the edges of the display panel to secure it to the display assembly.
3. Install the:
a. display bezel
NOTE: This is applicable only for non touch systems.
b. display assembly
c. battery
d. base cover
4. Follow the procedure in After working inside your system.
Display hinges
Removing the display hinge
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
c. display assembly
d. display bezel
NOTE: This is applicable only for non touch systems.
e. display panel
NOTE: This is applicable only for touch systems.
3. To remove the hinges:
a. Remove the screws that secure the display hinge to the display assembly [1, 3].
NOTE: The number of screws will vary for touch and non touch systems.
b. Remove the display hinge [2, 4].
