Dell M5200 Medium Workgroup Mono Laser Printer - Page 145

1.
CAUTION: The rear portion of the inside of the printer is hot.
While grasping the toner cartridge by the hand grip, pull the cartridge up toward the upper front door,
and then pull it straight out toward you.
2.
NOTICE: Never touch the photoconductor drum on the underside of the cartridge. Use the handhold
on the cartridge to avoid touching this area.
1
Photoconductor drum
Lay the cartridge aside.
NOTE: Do not leave the cartridge exposed to light for extended periods.
Gently push the feed roller release lever toward the back of the printer.3.
