Dell M5200 Medium Workgroup Mono Laser Printer - Cleaning the Printer

2.
CAUTION: The rear portion of the inside of the printer is hot.
While grasping the toner cartridge by the hand grip, pull the cartridge up toward the upper front door,
and then pull it straight out toward you.
3.
NOTICE: Never touch the photoconductor drum on the underside of the cartridge. Use the handhold
on the cartridge to avoid touching this area.
1
Photoconductor drum
Set it aside.4.
Cleaning the printer
