Attaching cables

Choosing the right cable

Connecting the printer locally

Connecting the printer to the network

Choosing the right cable

Your Dell Workgroup Laser Printer M5200 interconnection cable must meet the following requirements:

Connection

Cable certification

USB

USB 2.0

10/100BaseT Ethernet

CAT-5E

USB port

Ethernet port
