1
Photoconductor drum
Hold the toner cartridge by the handle and gently shake it side-to-side to distribute the toner.2.
Align the tabs on each side of the toner cartridge with the slots on each side of the cartridge cradle.
Use the arrows inside the printer for placement.
3.
1
Tab
2
Slot
4.
5.
