Dell M5200 Medium Workgroup Mono Laser Printer - Page 29

Attaching the wire bail
The wire bail keeps paper from sliding out of the output bin.
Remove the printer top cover and slide the plastic bracket onto the static brush holder. Adjust the
bracket so it is centered over the area where print media exits.
1.
1
Static brush holder
2
Plastic bracket
Place the tips of the wire bail into the ends of the plastic bracket so that the bail curves downward.2.
Replace the top cover.3.
