Replacing the base cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-4D946A21-3155-40D5-ABF4-BBB6C62D9D65
Status Released
Procedure
1 Slide the tabs on the base cover into the slots on the palmrest and keyboard
assembly and snap the base cover into place.
2 Replace the screws that secure the base cover to the palmrest and keyboard
assembly.
3 Replace the screw cover into its slot on the base cover.
