Removing the sensor board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-4E46E3EA-554A-40F3-9C8D-27FE14B3776C
Status Released
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Remove the wireless card.
4 Remove the display assembly.
5 Remove the display panel.
Identifier GUID-CFFF95DD-57C1-4D7A-BB5F-AF40BD079E57
Status Released
Procedure
CAUTION: Place the display-panel assembly on a soft and clean surface to
avoid scratching the display.
1 Open the latch and disconnect the sensor-board cable from the sensor board.
92
