Replacing the touchpad
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-E4A28CC0-433B-4923-B45E-1A913A49A7D9
Status Released
Procedure
1 Slide the tabs on the touch pad into the slots on the palmrest and keyboard
assembly.
2 Align the screw holes on the touch pad with the screw holes on the palmrest
and keyboard assembly.
3 Replace the screws that secure the touch pad to the palmrest and keyboard
assembly.
4 Place the keyboard cable over the touch pad.
5 Adhere the tapes over the touch pad.
6 Slide the touch-pad cable into its slot on the touch pad and press down the
latch to secure the cable.
Identifier GUID-FDEF6E44-83AD-41FD-9D1F-A77AC55AE182
Status Released
Post-requisites
1 Replace the battery.
2 Replace the base cover.
