Procedure
1 Open the latch and disconnect the I/O-board cable from the system board to
access the wireless card.
1 I/O-board cable 2 latch
2 Loosen the captive screw from the wireless-card bracket.
3 Disconnect the antenna cables from the wireless card.
4 Remove the screw that secures the wireless card to the system board.
