Replacing the display assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at
www.dell.com/regulatory_compliance.
Post-requisites
1 Replace the wireless card.
2 Replace the battery.
3 Replace the base cover.
Procedure
CAUTION: Place the computer on a soft and clean surface to avoid
scratching the display.
1 Place the display assembly on the palmrest and keyboard assembly.
2 Align the screw holes on the display hinges with the screw holes on the
palmrest and keyboard assembly.
3 Replace the screws that secure the display assembly to the palmrest and
keyboard assembly.
4 Turn the computer over and close the display.
5 Slide the display cable into its slot on the system board and press down
the latch to secure the cable.
6 Adhere the tape on the display cable.
7 Align the screw hole on the display-cable bracket with the screw hole on
the system board.
8 Replace the screw that secures the display-cable bracket to the system
board.
9 Slide the I/O-board cable into its slot on the system board and press
down the latch to secure the cable.
10 Route the antenna cable through its routing on the right speaker.
61
