Removing the I/O board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-A37DA783-8459-4BE5-A9AA-283D71CA3741
Status Released
Prerequisites
1 Remove the base cover.
2 Remove the battery.
3 Follow the procedure from step 1 to step 4 in “Removing the hard drive”(Only
for computers shipped with a hard drive).
Identifier GUID-AD483237-8033-4CDC-AB35-9DB2283BF53A
Status Released
Procedure
1 Peel o the tape that secures the sensor-board cable to the I/O board.
2 Open the latch and disconnect the sensor-board cable from the I/O board.
34
