4 Lift the hard-drive assembly o the palmrest and keyboard assembly.

NOTE: The images in this chapter may dier from your computer

depending on the processor you ordered.

1 screws (3) 2 hard-drive assembly

3 palmrest and keyboard

assembly

5 Remove the screws that secure the hard-drive bracket to the hard drive.
