Replacing the coin-cell battery
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-24B82B1F-054C-4A15-83E9-A8784CD6AC51
Status Released
Procedure
1 With the positive-side facing up, place the coin-cell battery into the battery
socket on the system board.
2 Route the coin-cell battery cable through its routing guides on the right speaker.
3 Connect the coin-cell battery cable to the system board.
4 Turn the I/O-board cable over to cover the coin-cell battery.
5 Slide the I/O-board cable into its slot on the system board and press down the
latch to secure the cable.
Identifier GUID-643EFFA1-35F6-474D-AF71-88CD3C8D9FCB
Status Released
Post-requisites
1 Replace the battery.
2 Replace the base cover.
