Replacing the camera
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-389229C2-0C28-4F31-AA49-3711F183FBAC
Status Released
Procedure
1 Connect the camera cable to the camera.
2 Using the alignment post, place the camera on the display-back cover and snap
it into place.
3 Slide the display cable into its slot on the display-back cover and close the latch
to secure the cable.
4 Adhere the tape on the display-cable connector.
5 Adhere the tape to secure the display cable to the display panel.
6 Slide the sensor-board cable into its slot on the sensor board and close the latch
to secure the cable.
Identifier GUID-3094F0BD-997B-4879-B9C4-369D4F025153
Status Released
Post-requisites
1 Replace the display panel.
2 Replace the display assembly.
3 Replace the wireless card.
4 Replace the battery.
