Identifier GUID-DA29E185-7F32-487B-84BE-13EA87BF6468
Status Released
Procedure
1 Open the latch and disconnect the I/O-board cable from the system board.
2 Disconnect the coin-cell battery and speaker cables from the system board.
1 coin-cell battery cable 2 speaker cable
3 system board
3 Remove the screws that secure the display-cable bracket to the system board
and lift the display-cable bracket o the system board.
69
