Replacing the sensor board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-58654872-E416-4EBA-93EB-BFA24F80F6AC
Status Released
Procedure
1 Align the sensor board on the display-back cover and snap the sensor board into
place.
2 Slide the sensor-board cable into the slot on the sensor board and press down
the latch to secure the cable.
Identifier GUID-6533870E-4E18-4754-B4A0-0A87ECBF3717
Status Released
Post-requisites
1 Replace the display panel.
2 Replace the display assembly.
3 Replace the wireless card.
4 Replace the battery.
5 Replace the base cover.
