Replacing the battery
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-F1D9829F-29E4-41EF-9109-84AC3DB0061C
Status Released
Procedure
1 Align the screw hole on the battery with the screw hole on the palmrest and
keyboard assembly.
2 Replace the screw that secures the battery to the palmrest and keyboard
assembly.
3 Connect the battery cable to the system board.
Identifier GUID-59DCA146-00BB-4363-BB90-AAFAFD074284
Status Released
Post-requisites
Replace the base cover.
