Installing memory module
1 Align the notch on the memory module with the tab on the memory-module slot.
2 Slide the memory module rmly into the slot at an angle and press the memory module down until it clicks into place.
NOTE
: If you do not hear the click, remove the memory module and reinstall it.
3 Install the:
a back cover
b USB dongle-bay cover
4 Follow the procedure in After working inside your computer
Hard drive
Removing HDD/SSD
NOTE
: The drive in the top slot of the drive carrier is the primary drive. The procedure for removing both primary and secondary
drive is the same.
1
Follow the procedure in Before working inside your computer.
2 Remove the:
16
Removing and installing components
