Installing USB-dongle port
1 Route the USB dongle port cable into the slot on I/O panel .
2 Route the USB dongle port cable through the routing guide on I/O panel .
3 Align the screw holes on the USB dongle port with the screw holes on the I/O panel.
4 Replace the three screws (M3X4) that secure the USB dongle port to the I/O panel.
5 Install the:
a I/O panel
b system-board shield.
c inner frame
d stand
e back cover
f USB dongle-bay cover
6 Follow the procedure in After working inside your computer
Removing and installing components
41
