Next steps
1 Replace the battery
2 Replace the base cover
3 Replace the SD memory card
4 Follow the procedure in after working inside your computer
Solid-state drive/Intel Optane memory module
Removing the M.2 2230 Solid-state drive
Prerequisites
1 Follow the procedure in before working inside your computer
2 Remove the SD memory card
3 Remove the base cover
4 Remove the battery
Steps
1 Loosen the captive screw that secures the thermal plate to the palmrest and keyboard assembly [1].
2 Remove the single (M2x3) screw that secures the thermal plate to the palmrest and keyboard assembly [2].
3 Slide and remove the thermal plate from the solid-state drive slot [3, 4].
Removing and installing components
25
