Next steps
1 Replace the battery
2 Replace the base cover
3 Replace the SD memory card
4 Follow the procedure in after working inside your computer
VGA Daughterboard
Removing the VGA daughterboard
Prerequisites
1 Follow the procedure in before working inside your computer
2 Remove the SD memory card
3 Remove the base cover
4 Remove the battery
Steps
1 Disconnect the VGA daughterboard cable from the VGA daughterboard [1].
2 Remove the two (M2x3) screws that secure the VGA daughterboard to the palm rest and keyboard assembly [2].
3 Lift the VGA daughterboard away from the system [3].
Removing and installing components
41
