Dell Vostro 3480 - Display Assembly Servicing

Next steps
1 Replace the battery
2 Replace the base cover
3 Replace the SD memory card
4 Follow the procedure in after working inside your computer
Display assembly
Removing the display assembly
Prerequisites
1 Follow the procedure in before working inside your computer
2 Remove the SD memory card
3 Remove the base cover
4 Remove the battery
5 Remove the WLAN
6 Remove the hard drive assembly
Steps
1 Peel o the tape securing the wireless antenna from the system board [1].
2 Open the latch and disconnect the display cable from the system board [2].
3 Unroute the display cable from the routing guides on the palmrest and keyboard assembly [3, 4].
